Product Introduction：ORA series LED video panel is designed for outdoor rental & stage application, has pixel pitch 2.6mm, 2.9mm, 3.9mm for option. Easy for maintenance. It is a economical led video panel for all kinds of events application scenario.
|
|
BOR-A-2.6 |
BOR-A-2.9 |
BOR-A-3.9 |
BOR-A-4.8 |
|
Physical Pitch |
2.6mm/0.1“ |
2.97mm/0.12” |
3.91mm/0.15“ |
4.8mm/0.19“ |
|
Pixel Configuration |
SMD1415 |
SMD1415 |
SMD1921 |
SMD1921 |
|
Pixel Density |
147456px/m2 |
112896px/m2 |
65536px/m2 |
43264px/m2 |
|
Module Dimension(WxH) |
250x250mm / 9.84"x9.84" |
|||
|
Panel Dimension(WxHxD) |
500x500x80mm / 19.68"x19.68"x3.14" 500x1000x80mm / 19.68"x39.37"x3.14" |
|||
|
No. of Module/panel(WxH) |
2x2/2x4 |
|||
|
Module Resolution |
96x96px |
84x84px |
64x64px |
52x52px |
|
Panel Resolution |
192x192px 192x384px |
168x168px 168x336px |
128x128px 128x256px |
104x104px 104x208px |
|
Panel Material |
Die-casting Aluminum |
|||
|
Panel Weight |
8kg/14kg (17.63lbs/30.86lbs) |
|||
|
Gray Scale |
16bit |
|||
|
Contrast Ratio |
4000:1 |
|||
|
Avg. Power Consumption |
64w/panel 128w/panel |
|||
|
Max. Power Consumption |
192w/panel 384w/panel |
|||
|
Operating Temp/Humidity |
-10°C - 60°C / 10% - 60% |
|||
|
Storage Temp/Humidity |
-30°C - 60°C/ 10% - 60% |
|||
|
Refresh Rate |
7680hz |
|||
|
Brightness |
≥4500nits |
|||
|
Viewing Angle(H/V) |
160°/140° |
|||
|
Expected Lifetime |
100,000hrs |
|||
|
Max. Stacking/Hanging |
20/10 |
|||
|
Service |
Rear |
|||
|
IP Rating(Front/Rear) |
IP65/IP54 |
|||
|
Certification |
CCC,CE,ETL,RoHS |
|||
