BOR-D Series

 BOR-D-2.6

 BOR-D-2.9

 BOR-D-3.9

 BOR-D-4.8

Physical Pitch

2.6mm/0.1“

2.97mm/0.12”

3.91mm/0.15"

4.8mm/0.19"

Pixel Configuration

SMD1415

SMD1415

SMD1921

SMD1921

Pixel Density

147456px/m2

112896px/m2

65536px/m2

43264px/m2

Module Dimension(WxH)

250x250mm / 9.84"x9.84"

Panel Dimension(WxHxD)

500x500x80mm / 19.68"x19.68"x3.14"

500x1000x80mm / 19.68"x19.68"x3.14"

No. of Module/panel(WxH)

2x2/2x4

Module Resolution

96x96px

84x84px

64x64px

52x52px

Panel Resolution

192x192px

192x384px

168x168px

168x336px

128x128px

128x256px

104x104px

104x208px

Panel Material

Die-casting Aluminum

Panel Weight

6kg/10.4kg (13.22lbs/22.92lbs)

Gray Scale

16bit

Contrast Ratio

4000:1

Avg. Power Consumption

64w/panel

128w/panel

Max. Power Consumption

192w/panel

384w/panel

Operating Temp/Humidity

-10°C - 60°C / 10% - 60%

Storage Temp/Humidity

-30°C - 60°C/ 10% - 60%

Refresh Rate

7680hz

Brightness

≥4500nits

Viewing Angle(H/V)

160°/140°

Expected Lifetime

100,000hrs

Max. Stacking/Hanging

20/10

Service

Front/Rear

IP Rating(Front/Rear)

IP65/IP54

Certification

CCC,CE,ETL,RoHS
