BGF Series

BGF-2.6-5.6

BGF-3.9-7.8

BGF-7.8

BGF-10.42

Physical Pitch

2.6-5.6mm/0.1"-0.22"

3.9-7.8mm/0.15"-0.31"

7.8mm/0.31"

10.42mm/0.41"

Pixel Configuration

SMD1R1G1B

Pixel Density

68352px/m2

32768px/m2

16384px/m2

9216px/m2

Module Dimension(WxH)

500x250mm/19.68"x9.84"

1000x250mm/39.37"x9.84"

Panel Dimension(WxH)

1000x1000mm/39.37"x39.37"

No. of Module/panel(WxH)

2x8

Module Resolution

192x89px

384x89px

128x32px

256x32px

64x32px

128x32px

48x24px

96x24px

Panel Resolution

384x178px

256x64px

128x128px

96x96px

Panel Material

Aluminum

Panel Weight

7kg / 15.43lbs

Gray Scale

16bit

Contrast Ratio

4000:1

Avg. Power Consumption

267w/m2

267w/m2

260w/m2

220w/m2

Max. Power Consumption

800w/m2

800w/m2

780w/m2

660w/m2

Operating Temp/Humidity

-10°C - 60°C / 10% - 60%

Storage Temp/Humidity

-30°C - 60°C/ 10% - 60%

Refresh Rate

3840hz

Brightness

600~5500nits(customized)

Viewing Angle(H/V)

160°/140°

Expected Lifetime

100,000hrs

Service

Front/Rear

IP Rating(Front/Rear)

IP30

Certification

CCC,CE,ETL,RoHS
