BD Series

BD-2.5

BD-2.6

BD-2.97

BD-3.91

BD-4.8

Physical Pitch

2.5mm/0.1"

2.6mm/0.102"

2.97mm/0.12"

3.91mm/0.15"

4.81mm/0.19"

Pixel Density

160000px/m2

147456px/m2

112896px/m2

65536px/m2

43264px/m2

Module Dimension(WxH)

250x250mm / 9.84"x9.84"

Panel Dimension(WxH)

500x1000mm / 19.68"x39.37"

500x500mm / 19.68"x19.68"

No. of Module/panel(WxH)

2x4

2x2

Module Resolution

100x100px

96x96px

84x84px

64x64px

52x52px

Panel Resolution

200x400px

200x200px

192x384px

192x192px

168x336px

168x168px

128x256px

128x128px

104x208px

104x104px

Panel Material

Cold steel / Aluminum / Die-casting AL

Panel Weight

44kg/m2

44kg/m2

44kg/m2

44kg/m2

44kg/m2

Gray Scale

16bit

Contrast Ratio

4000:1

Max. Power Consumption

800w/m2

800w/m2

800w/m2

800w/m2

800w/m2

Operating Temp/Humidity

-10°C - 60°C / 10% - 60%

Storage Temp/Humidity

-30°C - 60°C/ 10% - 60%

Refresh Rate

3840hz

Application

Indoor

Indoor

Indoor

Indoor

Indoor

Viewing Angle(H/V)

160°/140°

Expected Lifetime

100,000hrs

Service

Front

Certification

CCC,CE,ETL,RoHS
