BG-2.5-7.8 |
BG-3.9-7.8 |
BG-5-8 |
BG-10 |
BG-16 |
Physical Pitch |
2.5x7.8mm |
3.9x7.8mm |
5x8mm |
10.4x10.4mm |
16mm |
Pixel Configuration |
SMD1921 |
SMD1921 |
SMD1921 |
SMD1921 |
SMD1921 |
Pixel Density |
50688pixels/m² |
32256pixels/m² |
25000pixels/m² |
9216pixels/m² |
3906pixels/m² |
Module Dimensions (WxH)(mm) |
500x125 |
500x125 |
480x320 |
500x125 |
480x320 |
Panel Dimensions (WxH)(mm) |
1000x500 |
1000x500 |
960x640 |
1000x500 |
960x640 |
NO. of Modules Per Panel(WxH) |
2x4 |
2x4 |
2x2 |
2x4 |
2x2 |
Physical Resolution of Module(WxH) |
200x16 |
128x16 |
96x40 |
48x12 |
30x20 |
Physical Resolution of Panel(WxH) |
400x64 |
256x64 |
192x80 |
96x48 |
60x40 |
Panel Material |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
Aluminum |
Single Cabinet Weight |
<14kg/m² |
<14kg/m² |
<14kg/m² |
<14kg/m² |
<14kg/m² |
Gray Scale |
16bit |
16bit |
16bit |
16bit |
16bit |
Colours |
281 trillion |
281 trillion |
281 trillion |
281 trillion |
281 trillion |
Contrast Ratio |
2000:1 |
2000:1 |
2000:1 |
2000:1 |
2000:1 |
Average Power Consumption |
240W/m² |
180W/m² |
203W/m² |
140W/m² |
218W/m² |
Max. Power Consumption |
700W/m² |
560W/m² |
670W/m² |
400W/m² |
650W/m² |
Operating Temp/Humidity |
-10ºC-60ºC/ 10%-60% |
-10ºC-60ºC/ 10%-60% |
-10ºC-60ºC/ 10%-60% |
-10ºC-60ºC/ 10%-60% |
-10ºC-60ºC/ 10%-60% |
Storage Temp/Humidity |
-30ºC-60ºC/ 10%-60% |
-30ºC-60ºC/ 10%-60% |
-30ºC-60ºC/ 10%-60% |
-30ºC-60ºC/ 10%-60% |
-30ºC-60ºC/ 10%-60% |
Refresh Rate |
>1920Hz |
>1920Hz |
>1920Hz |
>1920Hz |
>1920Hz |
Brightness |
1000~4200 nits |
1000~4200 nits |
>5500 nits |
1000~4200 nits |
>5500 nits |
Horizontal Viewing Angle |
160° |
160° |
160° |
160° |
160° |
Vertical Viewing Angle |
140° |
140° |
140° |
140° |
140° |
Expected Lifetime |
100,000Hrs |
100,000Hrs |
100,000Hrs |
100,000Hrs |
100,000Hrs |
IP Rating(Front/Rear) |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
Servicing |
Rear |
Rear |
Rear |
Rear |
Rear |
Scan Method |
1/11 Scan |
1/7 Scan |
1/6 Scan |
1/2 or 1/4 Scan |
Static Scan |
