BT-2

BT-3

BT-5

Physical Pitch

2.5 mm

3.076 mm

5  mm

Pixel Configuration

SMD 1415

SMD 1415

SMD 2727

Pixel Density

160,000 pixels/m²

111,111 pixels/m²

40,000 pixels/m²

Module Dimensions (W × H) (mm)

320 ×  160

320  × 160

160 ×  160

Screen Size (mm)

960  × 320

960  × 384

960  × 320

Screen Resolution

384 × 128

312 × 124

192 × 64

Physical Resolution of Module (W × H)

128 ×  64

104 × 52

32 ×  32

Frame size (mm)

1,100 (L) x 410 (H)

164 (bottom) / 99 (top)

1,100 ( L) x 410 (H)

170(bottom) / 99 (top)

1,100 ( L) x 410 (H)

164(bottom) / 99 (top)

Panel Material

Aluminum

Aluminum

Aluminum

Screen Weight

26 kg

26 kg

23 kg

Gray Scale

16 bit

16 bit

16 bit

Colours

281 trillion

281 trillion

281 trillion

Contrast Ratio

4,000 : 1

4,000 : 1

2,000 : 1

Average Power Consumption

180 W/Set

80 W/Set

150 W/Set

Max Power Consumption

480 W/Set

250 W/Set

450 W/Set

Operating Temp/Humidity

-40℃- 75℃ / 10% - 90%

-40℃- 75℃ / 10% - 90%

-40℃- 75℃ / 10% - 90%

Storage Temp/Humidity

-30℃- 60℃ / 10% - 60%

-30℃- 60℃ / 10% - 60%

-30℃- 60℃ / 10% - 60%

Refresh Rate

> 1,920 Hz

> 1,920 Hz

> 1,920 Hz

Brightness

5,000nits

5,000nits

5,500nits

Driving Method

1/16 Scan

1/16 Scan

1/8 Scan

Horizontal Viewing Angle

160°

160°

160°

Vertical Viewing angle

140°

140°

140°

Expected Lifetime

100,000 Hrs

100,000 Hrs

100,000 Hrs

Servicing

Back

Back

Back

IP Rating (Front/Rear)

IP 65

IP 65

IP 65
